Specification

• Dimensions (D x H): 3 19/32″ x 1 15/16″ (91.6 mm x 49.5 mm)
• Weight: 7.1 oz (201 g), white; 6.2 oz (176 g), black
• Cable length: 19 ft 8″ (6 m)
• Temperature range: -22° to 176° F (-30° to 80° C), white; -22° to 149° F (-30° to 65° C), black
• Case material: Fully gasketed, high-impact plastic alloy; waterproof to IPX7
• Compass-safe distance: 5.9″ (150 mm)
• Power source input: 9-32 Vdc
• Input current: 150 mA at 12 Vdc
• NMEA 2000 Load Equivalency Number (LEN): 3 (150 mA)
• Position accuracy, typical marine use: < 1 meter CEP, < 3 meters, 95%
